OVERVIEW

This new concept in our range is made for the airtime lovers who don’t want to sacrifice the wave riding. The PATRIK F-Wave is most probably the fastest waveboard ever that still performs well in small to medium waves. With a Powerbox for the center fin of the thruster setup we leave it entirely up to you which fin to choose to go fast and jump high or ride waves and slice turns.
Following the success of the 75, 85 and 95, Patrik Diethelm shaped the 105 and 115 which are new for 2023. These bigger sizes have a new rockerline with increased Vee. They feel small on the wave, but carry all the volume you need to be the first one planing. If you love to play in different conditions, the new F-Wave is here for you!

SHAPE & CONSTRUCTION

OPTICAL ASPECT & FOOTPADS
With the new graphics influenced by Italian designer Fabio Canella we have created a colourful but still clean and classic board design. The 6mm thick diamond groove grip pad has an extra 6mm soft sponge under-layer which makes it 12mm in total. The special layup uses the hard layer to spread the load onto a wider board surface via the soft bottom layer of the pad. This gives us more impact resistance while keeping a direct feeling under your feet.

SHAPE
The very fast rocker line with rather little rocker is planning very quick. The “bat-tail” and side cut-outs have a similar effect like on a slalom board and release the water earlier and drive the board up to top speed in no time and make the board feel loose on the straight line and agile in the turns.

SCOOP-ROCKER
Very fast rocker line with little rocker for top planning, acceleration and top speed.

VOLUME DISTRIBUTION
Same as the QT-wave it has a balanced thickness under the feet and mast track to be close in contact with the fins for good control, grip and manoeuvrability but it is still thick enough to be able and push for top speed and high jumps.

OUTLINE
In comparison to the QT-wave it is wider at “1-foot” to be able and push even more for planning, acceleration and top speed. The cut-out on the tail bottom is a kind of hidden winger which reduces the tail width in the back-strap area and brings similar advantages. The reduced surface let the water release earlier and increases especially acceleration and top speed but it also helps to tilt the board over into the bottom turn and roll back easier into the cutback.

BOTTOM SHAPE
The goal was a fast controlled smooth ride and this we achieved with a single concave under the mast track running into a “double concaved V” under the straps on the two smaller boards while the bigger board performed best with the “double concaved V” running all the way through the bottom.

RAILS/TUCK
To improve the turning ability on the wider shape we reduced the rail thickness in comparison to the QT-wave. For better and faster release, the tuck is a bit sharper as well and improve the early planning acceleration and top speed.

DECK SHAPE
Flat decks are ankle breakers when it comes to push for top speed and the reduced rail thickness in combination with the slighty thicker center of the board makes the deck more domy and much more comfortable when fully planning in the straps. The extra dome under the back foot helps to get more grip during rotations.

FINS
The F-wave comes equiped with 3x PATRIK fins as a classic Thruster Setup with a bigger center fin and smaller side fins. This has proven to be the fastest setup for waves and jumping. The Center Powerbox allows the use of bigger Centerfins without the risk of breaking the board. The slot box sides save weight and leave you with enough trim options.

INSERTS
Each insert has 4-positions. The front strap has got a double plug to be able and change width and strap angle for different foot sizes and riding styles.

CONSTRUCTION
The topic where opinions split radically. But at the end of day let the advanced riders prove that our construction is built to last. The full carbon/kevlar deck is light and stiff with a good impact resistance. The Biax glass fibres on the bottom give you that controlled extra flex our riders love for the big turns and landings. Important fact: The softer biax glass spreads the load much better into the 3d construction than a full carbon bottom would. This results in better flex, better strength and better overall performance, while saving some money on production costs where it's not needed. Patrik Diethelms knowlede in composite construction is unmatched in the windsurf industry. This is our way of creating sustainable products that will last you many years when used correctly.

SPECS


	Length	Width	Volume	Tail Width at 300	Nose Width at 2000	Weight (+/-6%)	Strap Options	Straps	Fin Box
F-wave 75	2290	555	75	363	388	TBC	5×4	3	1x central Powerbox + 2x slot box
F-wave 85	2300	585	85	386	428	TBC	5×4	3	1x central Powerbox + 2x slot box
F-wave 95	2330	605	95	400	462	TBC	5×4	3	1x central Powerbox + 2x slot box
‌ F-wave 105	‌2340	‌630	1‌05	418	489	T‌BC	‌5×4	‌3	1x central Powerbox + 2x slot box‌
F-wave 115	2‌340	6‌55	‌115	437	518	‌TBC	‌5×4	‌3	1x central Powerbox + 2x slot box‌

Statt 2.749,00 EUR
Ab nur 1.949,00 EUR

2022 pd Patrik Boards f-ride (Freeride)

f-ride Freeride
Identischer Shape, identische Konstruktion, identischer Lieferumfang wie das 2026er Board, lediglich die Grafik ist etwas anders.

THE ONLY NARROW BODY SHAPE ON THE MARKET?

This shape is not followed by the trend and it is developed with true dedicated Freeriders. Wide body shapes are more stable for uphauling the sail but we agreed that this is needed more for entry level beginner boards and the Freerider is the more advanced rider with different needs. Our shape has a straighter outline and is a bit longer and the advantages are simply a more comfortable and balanced sailing position with planning and upwind performance

SHAPE DETAILS

Optical aspect & Footpad:

With the new graphic aspect influenced by Italian designer Fabio Canella we are taking a new direction and be more coloured while still keep it simple.

The 6mm thick over-dotted diamond groove grip pad has an extra 6mm soft sponge under-layer which makes it total 12mm and very nice and comfortable.

Shape Info “short”:

The extra length on the flat area under the straps is more stable across the axle and forgives wrong foot pressure so that the board keeps on riding like in cruise control modus. Besides that, passive planning (no pumping) is significantly better. The narrower width makes it easier to step into the straps and have both legs balanced in a comfortable position which makes any sailing direction especially going upwind much easier.

Shape Info “Detailed”:

Scoop-Rocker:

Extra longer flat between the straps for better passive planning and more longitudinal stability when sailing along.

Volume distribution:

An almost even foot position height under the straps makes the ride and the upwind sailing almost feel effortless and the flat deck provides the save standing platform.

Outline:

The narrower width and the more parallel lines are closer to the center line and makes it much easier to find the straps and step into the sailing position and keep on driving the board to the speed you feel comfortable with. As well the jibing is easier and the narrow width tilt effortless to the leeward side into the curve and the wider tail keeps the board length in the water and drive through the jibes much easier.

Bottom Shape:

Double concaved V with stabilizing side flats from nose to the front strap to absorb the chop and give it a comfortable ride and then blend into a flat panel V all the way to the tail for all-round cruising stability and easy rail to rail transitions in manoeuvres.

Rails / Tuck:

The boxy rails make the maximum width float stable in non-planning conditions. As well trough the jibe the rail floats nicely and just keeps on going through the whole turn. The sharp tail edges show a clean water release for best planning and acceleration performance.

Deck Shape:

Both strap positions are designed to have enough dome and curve to have a comfortable stance when using any of the inside or outside positions.

Fin boxes:

Deep Tuttle Foilbox

Inserts:

Inside and outside strap position on both straps with an extra center possibility in the tail area. Each insert has 4-positions for individual settings.

CONSTRUCTION

For this board the blind testing with plain white boards proved that our Biax glass fibre is the choice over the Carbon construction. The reason is simple, the Carbon hard and physical and distributes the vibration much more and the Biax glass fibre has the extra flex and absorbs the vibration for a more comfortable and controlled ride whereas most riders proofed to be faster on head to head speed tests.

DIMENSIONS

	Length [mm]	Width [mm]	Volume [litre]	Tail Width at 300 [mm]	Nose Width at 2000 [mm]	Weight (+/-6%) [kg]	Strap Options & Insert Holes	Strap Quantity	Fin Box
F-RIDE 125	2510	675	125	443	583	7,5	8X4	4	Foil deep tuttle
F-RIDE 135	2520	715	135	479	624	7,9	8X4	4	Foil deep tuttle
F-RIDE 145	2530	755	145	512	668	8,4	8X4	4	Foil deep tuttle
F-RIDE 155	2540	795	155	543	714	8,7	8X4	4	Foil deep tuttle

Statt 2.099,00 EUR
Ab nur 1.249,00 EUR

2022 pd Patrik Boards f-ride (Freeride) 145l...

f-ride Freeride 145l Volumen
Identischer Shape, identische Konstruktion, identischer Lieferumfang wie das 2026er Board, lediglich die Grafik ist etwas anders.

THE ONLY NARROW BODY SHAPE ON THE MARKET?

This shape is not followed by the trend and it is developed with true dedicated Freeriders. Wide body shapes are more stable for uphauling the sail but we agreed that this is needed more for entry level beginner boards and the Freerider is the more advanced rider with different needs. Our shape has a straighter outline and is a bit longer and the advantages are simply a more comfortable and balanced sailing position with planning and upwind performance

SHAPE DETAILS
